FPCway mainly do flex PCB and Rigid-flex PCB, and with our 10+ years experience, we also become a professional Rigid PCB and PCB Assembly manufacturer in Shenzhen China since 2013 for rigid PCB like 1-48L FR4 PCB, HDI PCB, Rogers PCB, Aluminum PCB, Copper PCB, and other rigid PCB. Our services including electronic design, PCB manufacture, PCB assembly, components sourcing, SMT stencil, PCB/PCBA copy services, box build, injection molding, CNC.



We are continually upgrading our full feature PCB service with better equipment, more training and more efficient techniques to provide the highest quality, full feature PCB manufacturing and assembly for our clients. We hold ourselves to the highest standards of quality and efficiency, and our clients know it, coming to us from industries like consumer electronic, IOT, Automatic, aerospace, medical, telecommunications and education.



The following is the form of our standard Rigid PCB capabilities, if beyond these or need detailed capabilities, please contact us.



Standard Rigid PCB Capability

Process

Items

Capability

Panel

Biggest Panel Size1-2Layer:700×1200mm
Multilayer:600×1100mm

PCB Thickness

Minimum PCB thickness0.06mm
Maximum PCB Thickness10.0mm
PCB Bow and Twist≤0.7%

Base Material

Base Material TypesFR4 (Standard TG, Middle TG, High TG, Halogen Free)
Polymide
Rogers
Aluminum
Copper
Teflon
ARLON

Copper Layer

Max Copper Layer48Layer
Inner Copper Thickness0.5/1/2/3/4/5/6OZ

Drilling

Minimum Hole SizeBoard thickness≤2.0mm,minimum holes 0.1mm
Board thickness>2.0mm,board thickness vs drill size=12:1
Blind/Buried ViasYes
Max hole Size6.0mm
PTH Tolerance±0.075mm
NPTH Tolerance±0.025

Plated Through Hole

Minimum Hole Wall Copper thickness20um
Aspect Ratio10:1

Circuit

Minimum Track Width/Space3mil/3mil
Minimum Space from Hole to Track0.18mm
Minimum Annular RingVias:3mil
Soldering Holes:6mil

Plating

Surface FinishHASL Lead free/with lead, Electrolytic Gold, Immersion Gold, Immersion Tin, Immersion Silver, OSP, Golden Finger, ENEPIG, etc.
Finished Copper ThicknessOuter Copper:1-10oz
Inner Copper:0.5-5oz
Electrolytic GoldNickle Thickness:100-200u”
Gold Thickness:1-50u”
Immersion GoldNickle Thickness:80-150u”
Gold Thickness:1-20u”
Golden FingerNickle Thickness:120-150u”
Gold Thickness:1-40u”

Etching

Original Copper thickness 1/3ozMinimum Track Width/Space:3mil
Original Copper thickness 1/2ozMinimum Track Width/Space:4mil
Original Copper thickness 1ozMinimum Track Width/Space:4-5mil
Original Copper thickness 2ozMinimum Track Width/Space:6mil
Original Copper thickness 3ozMinimum Track Width/Space:8mil
Original Copper thickness 4ozMinimum Track Width/Space:10.8mil

Solder Mask

Solder Mask ColorGreen, Blue, Red, Yellow, Black, White, Purple, Matt Black, Matt Green, Peelable Solder Mask,etc.
Solder Mask Opening2-4mil
Solder Mask BridgeMinimum:4mil (between two adjacent pads of IC)

Silkscreen

Silkscreen ColorWhite, Black, Yellow, Red, Blue, Green, etc.
Text Width5mil
Text Height30mil

Board Outline

CNC Tolerance±0.1mm
V-CUT Depth±0.1mm
V-CUT Deviation±0.1mm
V-CUT Angle20°, 30°, 60°
Distance from track to board outlineCNC:0.25mm
V-CUT:0.4mm

Reliability

Flame Retardance94v-0
Peel Strength12.3N/cm
Insulation Resistance≥109Ω
Impedance Control+/-5%, +/-10%
High-Voltage Insulation TestMinimum 1500V
thermal shock test288℃, 10seconds, 3times
